The LEAD K35/H35T 3.5 ton diesel forklift is designed for industrial material handling, pallet transportation and lifting operations involving heavy loads. With a rated capacity of 3,500 kg and a 500 mm load center, this diesel counterbalance forklift is a practical option for businesses that need to move materials efficiently in factories, logistics yards, warehouses and other suitable work environments.
The K35/H35T has a maximum lift height of 3,000 mm and a free lift height of 150 mm. Its rated unladen travel speed is 19 km/h, with a laden lifting speed of 400 mm/s. The maximum gradeability under load is 16%, subject to operating conditions and the specified load.
The forklift has an outside turning radius of 2,650 mm, an overall width of 1,240 mm and an overall length of 2,750 mm without forks. The mast lowered height is 2,070 mm, while the mast extended height with the load backrest is 4,065 mm. These dimensions help buyers assess whether the forklift is suitable for their work areas, access routes and material handling requirements.
With a service weight of 4,390 kg, the LEAD 3.5 ton diesel forklift is designed for regular material handling tasks in commercial and industrial settings. Potential applications include manufacturing, distribution, building material handling and logistics operations where loads need to be lifted, transported and positioned.
The supplied specification table lists the QC490BPG engine, rated at 39 kW at 2,650 rpm, and a 60 L fuel tank. Please confirm the engine configuration for the selected K35/H35T model before ordering.
Depending on the application, optional attachments such as sideshifters, fork positioners, rotators, paper roll clamps, bale clamps and carton clamps may be considered. Attachment selection must be checked against the forklift's mounting interface, hydraulic circuit requirements, load dimensions and residual lifting capacity. Not every attachment is suitable for every configuration.
Before choosing a 3.5 ton diesel forklift, consider the load weight, load center, required lifting height, aisle width, ground conditions and cargo type. Attachments and changes in load conditions can affect the forklift's available lifting capacity.
Contact LEAD to request detailed specifications, confirm the K35/H35T configuration and discuss suitable options for your material handling needs. Our team can help you review the product details before placing an order.
In the realm of heavy-duty industrial handling, every lift and transport of goods is crucial to efficiency and safety. Our newly launched 3.5T Four-Cylinder Diesel Forklift emerges as the ideal choice for enterprises aiming to boost logistics efficiency and reduce operational costs, thanks to its exceptional performance, innovative design, and reliable quality. It is not just a handling device but a powerful catalyst for your business growth.
I. Robust Power: Effortlessly Tackling Heavy-Duty Challenges
Equipped with a Huichai/Weifang 490/Yunnei four-cylinder diesel engine delivering 45/42kW power, this forklift utilizes advanced fuel injection technology and a turbocharging system to generate robust torque. With a 3500kg rated lifting capacity, it effortlessly handles full-load starts and 爬坡作业 (slope operations), ensuring stable and sustained power output. The 3800kg gross vehicle weight, combined with a 1360mm wheelbase and 1380mm track width, creates a perfect weight distribution, guaranteeing excellent stability during high-speed driving and turning. Even in complex working conditions, it inspires full confidence in drivers.
II. Sturdy Structure: Forging Durable Quality
The forklift’s mast is integrally formed from high-strength steel, with a standard lifting height of 3m. The 6° forward tilt and 12° backward tilt design of the mast effectively prevents cargo from sliding during loading/unloading and stacking, enhancing operational safety. The 1220mm extra-long forks, forged from special alloy steel and subjected to rigorous heat treatment, offer high strength and toughness. With a maximum outer adjustment of 1100mm, the forks adapt to various pallet and cargo sizes, meeting diverse handling needs. A 220mm ground clearance, paired with 28×9-15 front tires and 650-10 rear tires, ensures excellent passability, allowing the forklift to navigate smoothly across flat warehouse floors or gravel-covered outdoor sites, effortlessly overcoming obstacles.
III. Safety as a Priority: Protecting the Entire Operation
Safety is at the core of our design philosophy. The forklift is equipped with a sturdy full-steel overhead guard frame that meets international safety standards, effectively shielding drivers from falling objects and providing a reliable safety barrier. The hydraulic system features built-in anti-burst valves that swiftly activate to lock the mast in case of oil pipe bursts, preventing sudden cargo drops and avoiding safety incidents. Additionally, the vehicle is equipped with an intelligent sensing system that only allows startup when the driver is properly seated and wearing a seatbelt, eliminating risks from misoperations and ensuring comprehensive safety for operators.
IV. Human-Centric Design: Enhancing Operational Experience
The cockpit is designed with ergonomics in mind. The four-way adjustable steering wheel and suspended shock-absorbing seat can be precisely tailored to drivers’ heights and habits, effectively reducing fatigue during long drives. The operation handles are logically laid out to match the natural movements of the human hand, enabling easy and convenient operation—even during prolonged continuous use, fatigue is minimized. The dashboard features a high-definition LCD screen that real-time displays key vehicle data, such as speed, load weight, and engine status, allowing drivers to stay informed and make timely adjustments for efficient operations.
V. Flexibility and Efficiency: Adapting to Diverse Scenarios
With a minimum turning radius of 2400mm and a compact size of 2900×1380×2200mm, the forklift can maneuver flexibly in narrow warehouse aisles and crowded workshop environments, easily completing cargo handling and stacking tasks. A travel speed of 20km/h, combined with excellent power performance, significantly reduces cargo transportation time and improves operational efficiency. Whether it’s daily cargo handling in logistics and warehousing centers, heavy equipment transportation in factory workshops, or material handling on construction sites, the 3.5T four-cylinder diesel forklift delivers exceptional performance, thanks to its superior capabilities.
The 3.5T four-cylinder diesel forklift redefines the standards of heavy-duty handling with its robust performance, reliable safety guarantees, and human-centric design. Choosing our forklift means choosing efficiency, safety, and reliability—injecting strong momentum into your enterprise’s development and opening a new chapter in logistics handling.
