2T Four-Cylinder Diesel Forklift: Industrial-Grade Power with Precision Engineering for Efficient Handling

In the realm of medium-to-heavy material handling, reliability and efficiency are key to enhancing operational productivity. Our 2T Four-Cylinder Diesel Forklift is built on a foundation of robust four-cylinder power, combined with precision engineering and all-scenario adaptability. Designed for high-intensity environments such as warehouses, factories, and logistics centers, it redefines the value benchmark for 2-ton forklifts with hardcore parameters and human-centric details.

I. Four-Cylinder Power System: Stable Output & High Efficiency

Equipped with a Huichai/Weifang 490/Yunnei four-cylinder diesel engine (42kW power), featuring high-pressure common rail fuel injection technology, it delivers low-speed high-torque performance—ensuring smooth starts under full load and sustained power at high speeds, ideal for frequent stop-start warehouse operations and long-distance transportation. The high-position air filtration system blocks 98% of dust particles, extending engine maintenance cycles to 500 hours and reducing annual maintenance costs by 25%. With a gross vehicle weight of 3100kg and a golden ratio of 1360mm wheelbase/1380mm track width, it ensures high-speed stability and rollover resistance, performing consistently in complex conditions.

II. Safety Protection System: Multi-Dimensional Operational Security

Structural-Level Safety Assurance:Standard fully steel-reinforced overhead guard frame (compliant with ISO 6055 safety standards), capable of withstanding 200kg falling object impacts, creating a safety barrier for operators;The hydraulic system integrates an anti-burst valve device, which automatically locks the gantry when oil pipes burst, preventing sudden cargo drops within the 3m standard lifting height, enhancing safety by 40%;The seat gravity-sensitive switch interlocks with the emergency power-off button, disabling the power system when the driver is not seated to eliminate safety hazards from misoperations.

Vision & Control Safety:The wide-view formed doorframe design reduces pillar width by 12%, combined with a curved windshield to improve forward visibility by 30%, enabling precise cargo positioning during high stacking (load center distance 500mm);The full-hydraulic power braking system responds in <0.3 seconds. With 15° full load gradeability and 220mm ground clearance, the slope anti-skid function activates automatically on slippery surfaces or slopes, controlling full-load braking distance within 1.5m for reliable emergency stops.

III. Ergonomic Cockpit: Comfortable Control for Enhanced Efficiency

Driver-Centric Customization:Four-way adjustable steering wheel (up/down ±5cm/front/back ±3cm) and a suspended shock-absorbing seat adapt to drivers between 160-190cm in height, reducing waist pressure by 35% during long operations;The operation handle features an ergonomic curved grip, with hydraulic control precision up to 1mm, enabling fine adjustments of the fork’s 6° forward tilt/12° backward tilt, with stacking errors <5cm in narrow aisles.

Intelligent Interaction & Monitoring:A 5-inch LCD digital dashboard real-time displays 15 core data points, including engine speed, oil temperature, fuel level, and load weight (2000kg rated lifting capacity), with audible-visual alarms for anomalies (e.g., overload, overheating);Standard fault diagnosis interface allows quick reading of fault codes via specialized equipment, improving maintenance efficiency by 50% and reducing downtime losses.

IV. Durability & Economy: Maximizing Full-Life Cycle Value

Reinforced Core Components:Forks are forged from high-strength alloy steel (1070mm length, maximum outer adjustment 1100mm), with bending resistance up to 500MPa, compatible with various pallet sizes;The transmission system features a wear-resistant gearbox and imported bearings, with gear life exceeding 8,000 hours and oil change cycles extended to 500 hours (20% longer than similar products), significantly reducing maintenance costs.

Easy Maintenance Design:The engine compartment has a side-opening large maintenance door, reducing replacement time for consumables like filters and belts by 40%;Standard 650-9 rear tires and 28×9-15 front tires offer strong grip and wear resistance, with optional off-road tires for 30% improved all-terrain passability on gravel/muddy surfaces.

V. Scenario Adaptability: Flexible Performance Across Applications

Warehousing & Logistics:A 2400mm minimum turning radius and compact 1380mm body width (dimensions 2900×1380×2200mm) allow easy navigation through 2.5m-wide shelf aisles, with a 3m standard lifting height suitable for most warehouse high stacking;

Factory Handling:A 20km/h travel speed and 2-ton rated load efficiently transport finished products and raw materials in workshops, with a 12° mast back-tilt angle reducing cargo rollover risks;

Outdoor Operations:220mm ground clearance and reinforced chassis guard (optional) enable smooth passage over potholed factory roads, with 15° full load gradeability for slope loading/unloading tasks.

Three Core Advantages of the 2T Four-Cylinder Diesel Forklift

Reliable Power: Four-cylinder engine with precise tuning balances power output and fuel efficiency, handling medium loads with ease at 42kW;

Safety First: Structural protection, intelligent monitoring, and braking systems provide full-process safety for operators and cargo;

Long-Term Durability: 3100kg solid chassis, wear-resistant components, and easy maintenance design reduce full-life cycle costs by 20% compared to similar products, offering better ROI.

Unlock a New Era of Industrial Handling—from parameters to details, we deliver hardcore performance and human-centric design, empowering you to boost efficiency and reduce costs with confidence.
