4.5 T Professional Grade Multi Functional Diesel Forklift Buy

4.5T Diesel Forklift: Sleek design, wide-view frame, dust-resistant intake system, smart LCD instrument panel, and optional low-maintenance cast axle for durable industrial performance.
Model: LD-45DF
Rated lifting load: 4500 kg
Load center distance: 500 mm
Free lifting height: 160 mm
overall length(With fork/Without fork): 4120/3050 mm
Width: 1400 mm
Overhead guard height: 2230 mm
Wheelbase: 1900 mm
Minimum ground clearance: 150 mm
Mast tilt angle (front/rear): 6°/12°
Tire no. (before): 300–15–20PR
Tire no. (after): 7.00–12–12PR
Minimum turning radius (outer side): 2820 mm
Minimum right angle aisle width: 4830 mm
Fork size: 1070×150×50 mm
maximum working speed(Full-load/No-load ): 18/19 km/h
maximum lifting speed(Full-load/No-load ): 420/460 mm/s
maximum gradeability (Full-load/No-load ): 15/20 %
Forklift weight: 5860 kg
Engine model: Quanchai4C4–50V31
Product Detail Product Description
Description

Diesel Forklift

Diesel Forklift

Diesel Forklift

Diesel Forklift

Diesel Forklift

Diesel Forklift

Diesel Forklift

Diesel Forklift

Diesel Forklift

Diesel Forklift

Diesel Forklift

Diesel Forklift

Diesel Forklift

Diesel Forklift

Diesel Forklift

Warranty Info

4.5T Diesel Forklift: An Outstanding Choice for Industrial Material Handling

In the field of industrial material handling, efficiency and reliability are the eternal pursuits. Our 4.5T diesel forklift is precisely designed to meet these needs. It combines advanced technology with user - friendly design, making it an ideal partner for you to enhance the level of logistics operations.

I. Simple Appearance: A Blend of Aesthetics and Practicality

The overall appearance of the forklift follows a minimalist design concept, with smooth and natural lines. Without redundant decorations, it still exudes grandeur and beauty in its simplicity. This design not only endows the forklift with a unique visual charm, but more importantly, the simple appearance is easier to clean and maintain in daily use, reducing the accumulation of dirt and debris and keeping it in good working condition at all times.

II. Comfortable Operation: New Steering Wheel Adjustment Mechanism

It is equipped with a new steering wheel adjustment mechanism, which represents a significant upgrade in the operating experience. This mechanism supports multi - angle flexible adjustment. Whether the driver is tall or relatively petite, they can easily adjust the position and angle of the steering wheel according to their own needs. While improving operating comfort, the reliability of adjustment is also fully guaranteed. Through a large number of simulation tests and verification in actual working conditions, its structure is stable and can withstand long - term and high - frequency use, ensuring that each adjustment is accurate and in place, making the driving operation more handy.

III. High - efficiency Engine: High - Roof, Large - Diameter Intake System

The high - roof, large - diameter intake system is the "protector" of this forklift's engine. In the industrial environment, dust and impurities are often the enemies of the engine. However, through its unique design, this intake system can efficiently filter the outside air, greatly improving the cleanliness of the air entering the engine. This not only effectively reduces the wear and tear inside the engine, but also allows the engine's performance to be fully unleashed, with more stable and powerful power output. At the same time, it significantly extends the service life of the engine, reducing maintenance costs and downtime, providing a solid guarantee for the continuous and efficient operation of the enterprise.

IV. Expanded Vision: Wide - View Frame Design

The wide - view frame design represents a dual improvement in safety and operational convenience. By optimizing the frame structure and layout, it reduces blind spots, allowing the driver to observe the environment around the forklift and the status of the cargo more clearly and comprehensively during operation. Whether maneuvering through narrow warehouse aisles or working in complex loading and unloading areas, the driver can accurately grasp distances and positions, avoiding collisions and other accidents, greatly improving the safety and accuracy of operations, and thereby enhancing overall work efficiency.

V. Intelligent Interaction: LCD Digital Instrument and Friendly Interface

The reliable LCD digital instrument is the "intelligent assistant" for the driver. It can display all key parameters of the vehicle in real - time and accurately, such as driving speed, load weight, engine speed, fuel level, etc. Paired with a user - friendly interface, all information is clear at a glance, and the feedback of operation commands is rapid and accurate. The driver can quickly understand the vehicle's status through simple operations and make corresponding adjustments, achieving precise control over the vehicle and making each operation more efficient and safe.

VI. Economical and Practical: Optional Cast Steering Axle

Considering the different usage requirements and cost control of various customers, we offer an optional cast steering axle configuration. The cast steering axle is made of high - quality materials and advanced casting processes, featuring a sturdy structure and strong stability. During long - term use, its maintenance cost is relatively low, and the degree of wear is small, which can effectively reduce the frequency and cost of maintenance. For enterprises that pursue high cost - performance and long - term stable use, this is undoubtedly an attractive option.

This 4.5T diesel forklift demonstrates outstanding quality and performance in all aspects. Whether in large - scale logistics and warehousing centers or busy factory workshops, it can deliver excellent performance and help your business reach new heights.
