10-ton electric forklift - an efficient and energy-saving solution for heavy-load handling

Product Overview

It is a 10-ton electric forklift specially designed for heavy industrial applications. Equipped with advanced AC drive system and high-efficiency lithium battery technology, it meets the demanding operational requirements of industries such as ports, steel, and construction materials. Its outstanding carrying capacity, stable operational performance, and intelligent configuration redefine the industry standards for heavy-duty electric forklifts.

Core Advantages.

1. Exceptional load capacity, efficient operation

With a rated load of 10 tons and a standard load center distance of 600mm, it can easily handle large items such as heavy steel and building materials for transportation.

Double lifting motor design (25.4kW × 2) provides powerful power. The full-load lifting speed reaches 0.28m/s, and the efficiency is 20% higher than that of traditional fuel-powered forklifts.

15% full-load climbing slope, suitable for complex terrains such as warehouse slopes and outdoor storage areas.

2. Long-lasting battery life, energy-saving and environmentally friendly

High-capacity lithium battery pack (optional 80V/400Ah lead-acid or lithium battery), capable of supporting 8 hours of intense operation continuously, with a 30% improvement in charging efficiency.

Zero-emission electric drive, compliant with EU CE and international environmental protection standards, suitable for various indoor and outdoor scenarios.

3. Outstanding stability and safety

The wide track design (wheelbase of the driving wheels is 1480mm, and the wheelbase of the steering wheels is 1500mm) combined with a 2550mm long wheelbase significantly

enhances the handling stability and prevents rollover.

Hydraulic and mechanical dual braking system, combined with intelligent speed limit of 13 km/h (full load), ensures safety during heavy-load downhill driving.

The reinforced roof support (with a height of 2450mm) and LED panoramic lighting comply with OSHA safety standards.

4. Intelligent control, user-friendly

The AC AC control system offers faster response speed, reduces energy consumption by 15%, and supports regenerative braking energy recovery.

Adjustable floating seats (1350mm height) + multifunctional dashboard, reducing driver fatigue.

With a 3460mm small turning radius and a 5350mm narrow passage operation capability, it can flexibly handle containers and other narrow spaces.

5. Professionally adapted for heavy-duty conditions

8.25-15 pneumatic drive wheels + 250-15 solid steering wheels combination, providing both outdoor impact resistance and indoor floor protection.

85×175×1220mm thickened fork, specially designed for heavy goods such as steel coils and pallets, with a 50% increase in durability.

IP54 protection level, key components are dust and water resistant, suitable for harsh environments such as dust and humidity.

Typical application scenario

Heavy cargo transfer of containers at port terminals.

Transportation of ingots and coils at the steel plant.

Large-scale building materials storage and logistics center.

Heavy equipment manufacturing workshop.

Choose our 10-ton electric forklift, and you are choosing an efficient, reliable and sustainable solution for heavy-duty applications!
