200kg Sturdy And Durable Multi Functional All Terrain Tracked Skid Steer Loader Wholesale And Direct Sales

Zero-Turn Radius Maneuverability: Independent track drive enables 360 on-the-spot rotation, adapting to complex terrains.
Model: LD-T360
Engine brand: Electric/koop/Runtong/Zhongcheng/B&S
Rated power: 6kw、72V、125ah/7.5/8.6/8.5/9.9kw
Number of cylinders: 1
Air intake way: Naturally Aspirated
Emissions standards: EURO5/EPA
Rated operating capacity: 200Kg
Maximum operating capacity: 300Kg
Maximum breakout force: 3.5KN
Bucket capacity: 0.12m³
Driving speed: 0-6km/h
Total cycling time: 9s
System operating pressure: 17-21bar
Fuel tank capacity: 5L
Operating weight: 900KG
Track model: 180×72×35
Vehicle height: 1300mm
Length with standard bucket: 2070mm
Vehicle width (standard tire): 920mm
Length without standard bucket: 1640mm
Bucket width: 1050mm
Tail length: 500mm
Height at maximum extension: 2400mm
Height to the bucket pin: 1870mm
Maximum height as lay the bucket flat: 1720mm
Dumping height: 1510mm
Discharge distance: 250mm
Track contact with ground length: 900mm
Ground clearance: 130mm
The flip angle of the bucket on the ground: 27°
Bucket flip angle at highest position: 114°
Product Detail Product Description
Description

Tracked Skid Steer Loader

DETAIL PRESENTATION

Tracked Skid Steer Loader

Wheeled Skid Steer Loader

Tracked Skid Steer Loader

PRODUCT SELLING POINTS

 Tracked Skid Steer Loader

PRODUCT APPLICATIONS

 Tracked Skid Steer Loader

Tracked Skid Steer Loader

PRODUCT MANUFACTURING PROCESS

Tracked Skid Steer Loader

Tracked Skid Steer Loader

Tracked Skid Steer Loader

ABOUT US

Tracked Skid Steer Loader

Tracked Skid Steer Loader

PACKAGING AND TRANSPORT

Tracked Skid Steer Loader

Tracked Skid Steer Loader

MARKETING NETWORK

Tracked Skid Steer Loader

Tracked Skid Steer Loader

FAQ

Tracked Skid Steer Loader

Warranty Info

Narrow - space flexible - turning and tool - adaptation: The ultra - compact body can easily enter narrow spaces such as alleys and narrow passages in residential areas. The zero - radius turning technology enables the equipment to flexibly adjust the direction in a small space. The multi - modular tools are combined with the 1 - minute quick - change system. For example, in alley cleaning, it can quickly switch from bucket handling to breaker demolition of small illegal buildings, efficiently completing a variety of operations.

The coordinated operation of all terrain and powerful power: The all terrain adaptability of the tracked structure enables it to operate stably on different terrains such as sandy, muddy, and grassland. Performed outstandingly in high-intensity operations such as field construction and land consolidation in agriculture, forestry, and pastures, with strong and lasting momentum.

Precise - operation and intelligent - monitoring: The optimized hydraulic system enables precise operation and performs well in operations with high requirements for operation accuracy, such as shallow pit excavation for flower planting and handling of precision instruments. The intelligent control system monitors parameters such as oil temperature and rotation speed of the equipment in real - time and alarms in a timely manner once an abnormality occurs, ensuring the stable operation of the equipment and improving operation quality.

Long - life and widely - compatible: The low maintenance cost benefits from a simple and reliable structure. The key components are specially treated and have a long life. The industry - standard interface can be connected to a variety of international general accessories. Whether in the domestic or international market, it is convenient to obtain suitable accessories, improving the versatility and market competitiveness of the equipment.
